High-Precision V-Cut Automation
From 6 to 10 knives, FULILION's fully automatic V-Cut machines combine PLC control, servo-driven precision, powerful dust collection and MES connectivity — delivering fast, accurate V-Cut after routing while one operator runs the entire line. Request a QuoteProduction Pain Points
Common challenges in traditional PCB legend printing
Labor Cost
Traditional manual screen printing requires significant labor and screen-making costs.
Quality Issues
Film and screen production deformation causes quality defects and material waste.
Slow Delivery
Film and screen production takes time, delaying delivery to customers especially for small batches.
Inconsistent Quality
Manual alignment errors lead to inconsistent character quality and precision across production runs.
Equipment Configuration
Typical online configuration for fully automatic inkjet printing line
| Stage | Equipment | Model |
|---|---|---|
| Auto Loading | U-Rack Auto Loader | G-URAL302 |
| Front Buffer | Robot Loader/Unloader (Front) | G-PRS402F |
| Inkjet Printing | Legend Inkjet Printer (Dual Worktable) | F-LIP500-2X |
| Rear Buffer | Robot Loader/Unloader (Rear) | G-PRS402S |
| Panel Turnover | Panel Turnover Machine | G-PTM001 |
| Auto Unloading | U-Rack Auto Unloader | G-URAU303 |
| Optional: Curing | Hot Tunnel Oven | Connect at rear |
| Optional: Developing | Developing Machine + Scrubbing Machine | Connect at front |
Configuration can be customized based on customer requirements. Robots are used for loading and unloading, which is simple, convenient, and highly flexible.
Value & Benefits
What this solution delivers to your factory
Labor Saving
Replaces traditional manual screen printing, eliminating screen-making labor and reducing overall production costs.
Quality Improvement
CCD alignment accuracy of 35um eliminates manual errors. Fully enclosed ink circulation prevents nozzle blockage.
Faster Delivery
Production at any time without film and screen preparation — accelerates delivery to customers, especially for small and medium batches.
MES Integration
Online mode supports MES connectivity. Directly use Gerber data printing — connected to scrubbing, developing, and etching machines.
